Chamber size(W xD xH)mm : 100 x100x100
Outer size(W xD xH)mm: 250 x240x350
Max temperature: 1200℃
Working temperature: 1100℃
Power supply: 220V/1.2KW
Heating element : HRE Alloy resistance wire
Chamber material : Polycrystalline inorganic alumina ceramic fiber material prepared by wet vacuum filtration
Temp.Precision : ±1℃
Termocouple : N Type thermocouple
Temperature controller : Intelligent microcomputer PID temperature control instrument, SSR control, PID parameter self-tuning function; programmable 30 program segments, program temperature rise, program heat preservation, program cooling
Heating rate : 1-25℃/min free adjustment
Furnace structure : Furnace temperature control integrated structure
Equipment protection : Modular control, sound and light alarm signal will be sent out for over temperature and broken coupler in the working process, and the protection action will be completed automatically
Safety protection : The equipment is equipped with a circuit breaker, which will automatically pop open in case of short circuit leakage, which can protect the safety of equipment and operators
Furnace shell : High-quality cold-rolled steel plate CNC machine tool blanking processing, after welding, grinding, polishing, phosphating, pickling, surface electrostatic spraying plastic powder
Quality certificate : ISO9001 CE SGS TUV
Standard packing : 1. Furnace body 1 set 2. Temperature controller 1 set 3. Power cord 3 meters 4. Thermocouple 1 set 5. Manual 1 copy 6. Crucible pliers 1 set 7. High temperature gloves 1 pair
Optional : 1. Optional exhaust chimney for evacuation of volatile substances 2. Optional corundum crucible, furnace floor, shed board and other kiln furniture 3. Optional material recorder for online recording of temperature curves
Accesoris :
1. Furnace body
2. Temperature controller
3. Power cord 3 meters
4. Thermocouple
5. Instruction manual
6. Crucible pliers
7. High temperature glove
